Product description: marine electric lighting control cable used for power, lighting and general control of various ships in the rivers and seas, offshore oil platforms and other water structures.
marine electric lighting control cable used for power, lighting and general control of various ships in the rivers and seas, offshore oil platforms and other water structures. Marine power cables play a decisive role in the ship's power system and are the lifeblood of the entire ship. It is responsible for the transmission and distribution of electrical energy for various electrical equipment on board. The main parameters of marine power cables are model specifications, number of cores, combustion characteristics, rated voltage, temperature, nominal cross-sectional area and other main parameters. Its implementation standards are: IEC60092-350, IEC60092-353 or GB9331-88.
marine electric lighting control cable Structure description:
1 Conductor: Tinned stranded copper wire 2 Insulation: MGT + XLPE 3 Armor: Tinned copper wire braid 4 Outer sheath: polyolefin Reference standard: Structural design: IEC60092-350,353; Conductor: IEC60228 Class2; Insulation: IEC90092-351; Sheath: IEC60092-359; Flame retardant: IEC60332-3-22; Fire resistance: IEC60331; Halogen-free: IEC60754; Low smoke: IEC61034 Ambient temperature: -30 ℃-+ 70 ℃ 5. Combustion characteristics of cables Single vertical flame retardant (/ DA) type cable can withstand the single vertical burning test specified in GB12666.5 (IEC332-1), and bunched flame retardant (/ SA) type cable can withstand GB12666.5 (IEC332-3) requirements 'S beam burning test; Low-smoke and low-halogen bunched flame-retardant (/ SB) type cable can withstand the bunched burning test specified in GB12666.5 (IEC332-3), and the smoke concentration during combustion meets the requirements of GB12666.7 (IEC1034). The content should be ≤100MG / G (in accordance with the requirements of IEC754-1); Low-smoke, halogen-free bunched flame-retardant (/ SC) cable can withstand the bunched burning test specified in GB12666.5 (IEC-332-3), and the water-soluble PH value of the gas emitted from the combustion is ≥4.3, and the conductivity is ≤10μSmm (in accordance with IEC74 -2 requirements).
